Our Products

Energy Saving TransformersYes! I am interested
Toroidal Transformer offer many advantages over a conventional Energy Saving & Three-Phase Transformers (Auto) 1-PH & 3-PH. Toroidal has a round shape with no air gaps, and with the primary and secondary windings uniformly distributed around the core,"locks in" the magnetic field and makes the toroidal transformer very quiet and efficient.

Toroidal Transformer,by meeting today’s requirements for smaller,more efficient,quieter and safer products,are being accepted in an increasing range of electronic and electrical equipment.With toroidal transformer smaller dimensions, lighter weight and low stray magnetic fields,you can build more compact,lower cost quality products without sacrificing performance. The main purpose of these transformers is used in energy saving technology which in turn enhances the performance and saving the energy. We have both in single phase and cascaded in three phase as per the utility by the customer.
Audio Out Put TransformerYes! I am interested
Audio Out Put Transformer must have very low leakage inductance in order to maintain high-frequency bandwidth with capacitive loads.Because of this, they rarely use Faraday shields and are often Multifilar wound. For low insertion loss, they use relatively few turns of large wire to decrease winding resistances.

Since they use fewer turns and operate at relatively high signal levels, output transformers seldom use magnetic shielding. On the other hand, input transformers directly drive the usually high-resistance, low capacitance input of amplifier circuitry. Many input transformers operate at relatively low signal levels, frequently have a Faraday shield, and are usually enclosed in at least one magnetic shield.

Audio transformers are used because they have two very useful properties. First, they can benefit circuit performance by transforming circuit impedances, to optimize amplifier noise performance for example. Second, because there is no direct electrical connection between its primary and secondary windings, a transformer provides electrical or Galvanic Isolation between two circuits.

Isolation in signal circuits is a powerful technique to prevent or cure noise problems caused by normal ground voltage differences in audio systems. To be truly useful, a transformer should take full advantage of one or both of these properties but not compromise audio performance in terms of bandwidth, distortion, or noise.

For further details, Kindly refer the attached pdf.file
SMPS TransformersYes! I am interested
The design of a switch mode power transformer will differ depending upon the type of circuit used. There are many variations of switching mode power supplies, but they can be narrowed down to three basic circuit configurations (each also has a mirrored configuration); Buck, Boost, and fly back. Be aware that the name for the Buck circuit varies from industry to industry and from person to person. It may also be referred to as an inverter, D.C. converter, forward converter, feed forward, and others. There are also unipolar and bipolar (push-pull) versions.

Features :

Wire HarnessYes! I am interested
We are engaged in offering of Wire Harness. The cables are bound together by clamps, cable ties, cable lacing, sleeves, electrical tape, conduit, a weave of extruded string, or a combination thereof. The company manufactures specialized cable assembly for white goods, office automation, and medical diagnostic equipment, electrical and electronic equipment.

Latest Manufacturing Equipment :

Power Transformers Single PhaseYes! I am interested
Miracle designs and manufactures E& I Power Transformers Single Phase for a variety of power supply and power conversion applications. Power transformers may be designed in a wide variety of shapes and sizes.

Specification :

Audio Line Matching TransformersYes! I am interested

Audio Line Matching Transformers is to match the Impedance of the loudspeaker or a number of loudspeakers to the optimum load of the tube or transistor. In other words, the transformer transforms the Impedance of the speaker, so that the impedance which it presents to the primary winding is equal to the load of the Output stage active element (tube to transistor).


Features:



Volume Control Audio AttenuatorYes! I am interested
Volume Control Audio Attenuator are constructed with the help of 100V transformers. This control switch comes with 11 volume steps (10 regulator steps and 1-zero position) and besides this , they have a E/M relay (24VDC) which makes emergency announcements possible even if control is at position "0".

Features :

UI TransformersYes! I am interested
Our range of UI Transformers (flat-series) is manufactured using high quality electrical components and sophisticated technology. It is widely appreciated for features like reliability, optimum performance and durability.

Features:


Welcome to

Miracle Electronic Devices Private Limited

Miracle Electronic Devices Private Limited”, is an AS 9100 C,  ISO 9001:2008 / 2003:13485 Certified Company, which is engaged in manufacturing, supplying and exporting Power & Industrial Transformers, Voltage Stabilizers and Power Supply. Products incorporated in this range are Toroidal Single phase Transformers, Toroidal Three Phase Transformers, Flat Transformers, Toroidal 3 Phase Transformer, Audio Line Matching Transformers, EI Transformers and Halogen Transformer, Box Building, E & I Single and Three Phase Transformers,Energy Saving Transformers, Medical Grade Isolation Transformers, Wire Harness, Cable Assembly to name a few. This range is manufactured utilizing premium grade raw material, sourced from dependable vendors of the market. The offered range is appreciated for low power consumption and durability. We have acquired membership from Exports Electronic & Software Promotion Council of India, ITPO, Indo German Chamber of Commerce & Fkcci Kassia Bansia Pia Clik, IPC.

Leveraging on the vast experience of our professionals, we are committed towards offering quality range of products to clients. In order to achieve this goal, our professionals strictly follow the established norms and standards of the industry while manufacturing these products. Also, our professionals stay in continuous touch with the customers, so as to understand their requirement in a precise manner. All these professionals also ensure safe and timely delivery of these products at our clients destination. Owing to all the above mentioned factors, we have mastered a cluster of clients such as Bosch Limited, Bangalore, Karnataka and Coffee day, Bangalore, Karnataka to name a few and across the world like Australia, USA, Germany, Sweden, Singapore, France, Finland, China, Switzerland,East Europe and Central America, to name a few. Leveraging on the vast experience of our professionals, we are committed towards offering quality range of products to clients. In order to achieve this goal, our professionals strictly follow the established norms and standards of the industry while manufacturing these products. Also, our professionals stay in continuous touch with the customers, so as to understand their requirement in a precise manner. All these professionals also ensure safe and timely delivery of these products at our clients destination. Owing to all the above mentioned factors, we have mastered a cluster of clients such as Bosch Limited, Bangalore, Karnataka and Coffee day, Bangalore, Karnataka to name a few and across the world like Australia, USA, Germany, Sweden, Singapore, France, Finland, ChinaSwitzerland,East Europe and Central America, to name a few.

We are majorly dealing in bulk orders.
